Type | Sample (Days) | Massive prod. (Days.) |
---|---|---|
Through hole | 5~10 | 7~13 |
HDI | 8~12 | 12~22 |
Anylayer | 12~18 | 18~32 |
High frequency/ High speed | 5~10 | 6~12 |
FPC | 5~10 | 8~16 |
R & F | 12~18 | 18~28 |
Metal based | 5~12 | 8~18 |
Pingtai provides Printed Circuit Board Design (PCB Layout) Services for various engineering groups with a focus on Design for Fabrication and Design for Test.
*Capabilities & Services
*Schematic capture, bill of materials generation
*Board artwork, SMT solder paste stencil artwork, CAM data generation
*Assembly drawings, fabrication drawings
*Multi-layer boards, split ground planes, differential pairs, high speed rules
*Routing per trace/space, keep-out, and clearance rules specified by customer
*Component resequencing based on physical layout, reverse annotation to schematic
*DFT audit, test point placement, test probe clearance per customer rules, testability report
PCB Manufacturing: Single Side PCB | Double Side PCB | Multilayer PCB | Rigid Flexible PCB | Flexible PCB | Impedance PCB | HDI PCB | MCPCB
Pingtai offers PCB production service with a variety of PCB types and quantities. Your full range of board requirements can meet with, including single-sided, double-sided, and multi-layer(up to 68 layer) circuit board, material with CEM-1, FR-4, FR4 High TG, PTFE, Aluminum Base, Rogers, Specialized material per your request.
Send us your boards gerber files now, quotation can be provided within 24 hours.
